DNC Software
Description of our DNC software
Our V24Link program for Windows 95/98/ME/NT/2000 helps you to manage NC programs for a wide range of machines and their transfer to and from any connected machines.
Graphic representation of all machines:
The machined are displayed on your monitor just as they are arranged in your plant.
Each machine can be configured separately. Directories for incoming and outgoing data can, for example, be set and adjusted separately.
Machine-generated data names can be set individually.
Starting from the "Light with SAF" version, the software comes with a "send request" (Sendeanforderung). Programs can now called up via the machine, thus making a trip to the PC a thing of the past.
All machine and program-specific parameters are protected by an individually programmable password, thus ensuring that only authorised staff has access to this data.
Password in the demo version:"cnc"
| Bezeichnung | Lieferumfang | Preis |
| V24Link/WinXX 'Light' without SAF | A maximum of 1 machine active at any one time, not equipped with "send request", comes with instruction manual, ideal for running lap-tops | € 385,-- |
| V24Link/WinXX 'Light' with SAF | As above, however, including "send request" | € 550,-- |
| V24Link/WinXX 'Business' | A maximum of 4 machines active at any one time, equipped with "send request", comes with instruction manual | € 1.760,-- |
| V24Link/WinXX 'Business Plus' | As 'Business', but including customised 4-phase serial interface card | € 1.937,- |
| V24Link/WinXX 'ProfiDNC' | Professional version for up to 64 active machines or more, otherwise identical to the 'Business' package, including multi-phase serial interface card and a module for 8 machines, comes with instruction manual | ab € 2.987-- (please request a personal estimate) |
